Square D/Sorgel 1500 KVA 12470-4160GY/2400V Medium Voltage Dry Type Transformer R&G

Product description:

Square D/ Sorgel Medium Voltage Dry Type Transformer: 1500 KVA, High Voltage: 12470 Volt Delta- 69.4 A- 60 KV BIL, Low Voltage: 4160GY/2400 Volt- 208.0 A- 30 KV BIL, 3 Phase, 60 Hz, NEMA 1 indoor. Reconditioned with 1 year Warranty.

• PowerDry Aluminum Wound
• 150°C Temp Rise
• Ins. System Imp: 6.24%
• Ser# 034123-A1
• Taps:
  • 13094
  • 12782
  • 12470
  • 12158
  • 11847
• NEMA 1 Enclosure
• 94"H x 108"W x 54"D
• 8590 lbs
• Reconditioned with 1 year Warranty.

LOC: Pillar 185
