Cutler-Hammer Pow-R-Line Switchboard 3000 Amp Main Breaker 480Y/277 Volt 3 Ph 4 W NEMA 1 R&G

Product description:

Cutler-Hammer Pow-R-Line Switchboard; 3000 amp main breaker, 480Y/277 volt, 3 phase, 4 wire, ground fault, NEMA 1 indoor rated. With 2 sections of breaker distribution. Reconditioned & guaranteed with a one-year warranty.

3 Sections

Main Breaker Panel

• Eaton IQ 100 Meter
• Clipper Power System Surge Protection Device
  • 200 kA
• 3000 Amp Magnum DS Main Breaker
  • MDSC30
  • Cat # MDSC303HEA 305GA MNN2E PKNAX
  • Digitrip 520 Trip Unit
    • LSIG Functions
    • Cat # 5LSIG
    • Ground Fault

Breaker Distribution Panel 1

• 2000 Amp Breaker
  • RD 65k
  • Cat # RD320T36W
  • Digitrip 310 Trip Unit
    • Cat # RES2000LSIG
    • LSIG Functions
    • Ground Fault
  • Rating Plug
    • Cat # 20RES20T
    • 2000 Amp

Breaker Distribution Panel 2

• (2) 1200 Amp
  • HND 65k
  • Cat # HND312T36W
  • Digitrip RMS 310 Trip Unit
    • Ground Fault
  • Rating Plug
    • Cat # 12NES1000T
• (1) 800 Amp
  • HMDL 65k
  • Cat # HMDL3800F
  • Trip Unit
    • Cat # MT3800T
• Miscellaneous Breakers

Dimensions:

• Main Panel
  • 36" Width
  • 30" Depth
  • 90" Height

• Distribution Panel 1
  • 30" Width
  • 30" Depth
  • 90" Height

• Distribution Panel 2
  • 36" Width
  • 30" Depth
  • 90" Height

M-668                  LOC: Main Breaker Panel- Pillar 144 (F-11)    Dist 1 Panel- Pillar 143      Dist 2 Panel- Pillar 143
