Cutler-Hammer Pow-R-Line Switchboard 3000 Amp480Y/277 Volt 3 Ph 4 W NEMA 1 R&G

Product description:

Cutler-Hammer Pow-R-Line Switchboard; 3000 amp main breaker- cat # SPB 100, 480Y/277 volt, 3 phase, 4 wire, LSI functions, NEMA 1indoor rated. With 1 section C-series distribution. Reconditioned & guaranteed with a one year warranty.

2 Sections: From Left to Right

SPB Main Breaker Panel

• 3000 Amp Main Breaker
  • SPB 100
  • 3 Pole
  • Digitrip RMS 510 trip unit
    • Cat # S52LSI
    • LSI Functions
  • 3000 Amp Rating Plug
    • Cat # RP6S30A300

C-Series Breaker Distribution Panel

• (2) 1200 Amp
  • Cat # HND312T32W
  • Digitrip RMS 310 Rating Plug
    • Cat # 12NES1200T
• (2) 600 Amp
  • Cat # HLD3600F
  • Digitrip RMS 310 Trip Unit
    • Cat # 6LES3600LSI
  • 600 Amp Rating Plug
    • Cat # 6LES600T
• (1) 600 Amp
  • Cat # HLD3600F
  • Digitrip RMS 310 Trip Unit
    • Cat # LES3600LSI
  • 500 Amp Rating Plug
    • Cat # 6LES3500
• (1) 400 Amp
  • Cat # HKD3400F
  • Digitrip RMS 310 Trip Unit
    • Cat # KES3400LSI
  • 400 Amp Rating Plug
    • Cat # 4KES400T

Dimensions:

• Main Panel
  • 36" Width
  • 36" Depth
  • 90" Height

• C-Series Distribution Panel
  • 45" Width
  • 36" Depth
  • 90" Height

M-664               LOC: Pillar 126 (C-5)
