General Electric AV-Line Switchboard QA-3033-CBC | 3000 Amp Main-Tie-Main | 480Y/277V 3-Phase 4-Wire | NEMA 1 R&G

Product description:

General Electric AV-Line Switchboard; 3000 amp main-tie-main- cat # QA-3033-CBC, 480Y/277 volt, three phase, four wire, ground fault, NEMA 1 indoor. With (7) QA fusible switch distribution panels. Reconditioned and guaranteed with a one-year warranty.

9 Sections

(2) Fusible Main Sections

• Fusible Pringle Main
  • Cat# QA-3033-CBC
  • Serial# F-06688 & F-06687
  • 3000 Amp
  • 480 Volt
  • 60 Hz
  • Three Phase
  • Four Wire
  • Dwg# M-55400
  • Ground Fault

• Fusible Distribution Sections (7)
  • (5) QA-0833-B
    • 800 Amp
    • 480 Volt
  • (3) QA-0833
    • 800 Amp
    • 480 Volt
  • (1) QA-0833-CBC
    • 800 Amp
    • 480 Volt
  • (1) QA-1233
    • 1200 Amp
    • 480 Volt

Dimensions: 9 Sections From Left to Right

• Main 1
  • 60" Width
  • 40" Depth
  • 90" Height
• Tie 1
  • 30" Width
  • 40" Depth
  • 90" Height
• Tie 2
  • 30" Width
  • 40" Depth
  • 90" Height
• Tie 3
  • 30" Width
  • 40" Depth
  • 90" Height
• Tie 4
  • 45" Width
  • 40" Depth
  • 90" Height
• Tie 5
  • 30" Width
  • 40" Depth
  • 90" Height
• Tie 6
  • 30" Width
  • 40" Depth
  • 90" Height
• Tie 7
  • 30" Width
  • 40" Depth
  • 90" Height
• Main 2
  • 60" Width
  • 40" Depth
  • 90" Height

M-478      LOC: Pillar 144/145
