General Electric AV-Line THPR3616 Switchboard 1600A 125V DC NEMA 1 R&G

Product description:

General Electric AV-Line THPR3616 Switchboard; 1600 amp high pressure contact switch, 125 volt DC, 3 poles, NEMA 1 indoor. With (2) sections of fusible QMR distribution. Reconditioned and guaranteed with a 1 year warranty.

3 Sections: From Right to Left

General Electric Main Fusible Section

• High Pressure Contact Switch
  • Cat# THPR3616
  • 1600 Amp
  • 125 Volt DC
  • 3 Pole

QMR Distribution Panel 1

• (1) QMR221
  • 30 Amp

• (2) QMR222
  • 60 Amp

• (2) 600 Amp

QMR Distrubution Panel 2

• (4) 400 Amp

Dimensions:

• Main Panel
  • 30" Width
  • 30" Depth
  • 90" Height

• Dist 1 Panel
  • 40" Width
  • 30" Depth
  • 90" Height

• Dist 2 Panel
  • 40" Width
  • 30" Depth
  • 90" Height

M-645                    Pillar 154
