Siemens

15-3AFR-500-37 Siemens Vacuum Conversion; 1200A, 15 KV. Electrically operated, draw-out, motor: 208-254 VAC, close: 208-254 VAC, trip: 28-56 VDC. Used Electrically OK.

Siemens 5-GMI-250-2000-58 AC high voltage circuit breaker; rated max. volts: 4.76 kV, volt range factor: 1.24K Bil. kV, 60 rated short circuit kA: 29, close latch kA 58, interrupting time: 5 cycles. Electrically operated, motor: 100-140 VDC, 2.5 amps. nominal close: 100-140 VDC, 3.8 amps. nominal trip: 70-140 VDC, 3.8 amps. nominal draw-out, used electrically OK.

Siemens Part # 5-GMI-350-3000-78 GMI AC high voltage circuit breaker; 5 KV max, 3000 amp. Electrically operated, draw-out, 100-140 VDC control voltage, MFG date 02/2009. New Surplus

ITE/Siemens BDEH3100 breaker style bus plug; 100 amp, 480 volt, three-wire. Reconditioned and guaranteed with a one year warranty.

ITE/Siemens BDEH4100 breaker style bus plug; 100 amp, 480 volt, four-wire. Reconditioned and guaranteed with a one year warranty.

ITE/Siemens BDFJ4225 breaker style bus plug; 225 amp, 600 volt, four-wire. Reconditioned and guaranteed with a one year warranty.

ITE/Siemens BDJK3400 breaker style bus plug; 400 amp, 600 volt, three-wire. Reconditioned and guaranteed with a one year warranty.

ITE/Siemens BDKM3800 breaker style bus plug; 800 amp, 600 volt, three-wire. Reconditioned and guaranteed with a one year warranty.

ITE/Bulldog BEC3100 breaker style bus plug; 15-100 amp max circuit breaker enclosure, (240, 480 or 600 volt AC), 3 wire. ITE frame circuit breaker ED2, ED4, or ED6. Reconditioned & guaranteed with a one year warranty.

ITE/Bulldog BEC4100 breaker style bus plug; 15-100 amp max circuit breaker enclosure, (240, 480 or 600 volt AC), 4 wire. ITE frame circuit breaker ED2, ED4, or ED6. Reconditioned with a one year warranty.

ITE/Bulldog BFC3250 breaker style bus plug; 70-250 amp circuit breaker enclosure, 600 volt AC, 3 wire. ITE frame circuit breaker FD6 or FXD. Reconditioned with a one year warranty.

ITE/Bulldog BFC4250 breaker style bus plug. 70-250 amp circuit breaker enclosure, 600 volt AC, 4 wire. ITE frame circuit breaker FD6 or FXD. Reconditioned with a one year warranty.

ITE/Bulldog BJC3400 breaker style bus plug; 200-400 amp circuit breaker enclosure, 240 or 600 volt AC, 3 wire. ITE frame circuit breaker JXD6, JXD2, or JD6. Reconditioned with a one year warranty.

ITE/Bulldog BJC4400 breaker style bus plug; 200-400 amp circuit breaker enclosure, 240 or 600 volt AC, 4 wire. ITE frame circuit breaker JXD6, JXD2, or JD6. Reconditioned with a one year warranty.

ITE/Bulldog BLC3600 breaker style bus plug; 250-600 amp circuit breaker enclosure, 600 volt AC, 3 wire. ITE frame circuit breaker LXD6 or LD6. Reconditioned with a one year warranty.

ITE/Bulldog BLC4600 breaker style bus plug; 250-600 amp circuit breaker enclosure, 600 volt AC, 4 wire. ITE frame circuit breaker LXD6 or LD6. Reconditioned with a one year warranty.

ITE/Bulldog BMC3800 breaker style bus plug; 400-800 amp circuit breaker enclosure, 600 volt AC, 3 wire. ITE frame circuit breaker MD6. Reconditioned with a one year warranty.

ITE/Bulldog BMC4800 breaker style bus plug; 400-800 amp circuit breaker enclosure, 600 volt AC, 4 wire. ITE frame circuit breaker MD6. Reconditioned with a one year warranty.

ITE/Bulldog BOS14321 fusible style bus plug; 30 amp, 240 volt, 3 wire. Reconditioned with a one year warranty.

ITE/Bulldog BOS14323 fusible style bus plug; 100 amp, 240 volt, 3 wire. Reconditioned with a one year warranty.
