Square D Power Style Switchboard RGF36160U44A | 1600 Amp Main Breaker | 480Y/277V 3-Phase 4-Wire | NEMA 1 R&G

Product description:

Square D Power Style Switchboard; 1600 amp main breaker- cat # RGF36160U44A, 480Y/277 volt, 3 phase, 4 wire, ground fault, NEMA 1 indoor rated. With (1) section of I-line distribution panel. Reconditioned & guaranteed with a one-year warranty.

2 Sections: From Left to Right

Main Breaker Panel

• 1600 Amp PowerPact Main Breaker
  • RG 1600
  • Cat # RGF36160U44A
  • Micrologic 6.0 A Trip Unit
    • LSIG Functions
    • Ground Fault

I-Line Breaker Distribution Panel

• (1) MA36800
  • 800 Amp
• (3) KA36200
  • 200 Amp
• (1) KA36150
  • 150 Amp
• (2) FA36100
  • 100 Amp
• (2) FA36070
  • 70 Amp
• (1) FA36060
  • 60 Amp
• (1) FA34060
  • 60 Amp
• (8) FA36030
  • 30 Amp
• (1) FA34030
  • 30 Amp
• (2) FA34020
  • 20 Amp
• (1) FA36015
  • 15 Amp

Dimensions:

• Main Panel
  • 36" Width
  • 24" Depth
  • 90" Height

• Distribution Panel
  • 48" Width
  • 24" Depth
  • 90" Height

M-754                         LOC: B-3
