Square D

Square D NW16L1 Masterpact circuit breaker; cat# WA8EER63B3DXBXXXCA, 1600 amp frame, 600 volt AC, three pole. With 1600 amp rated Micrologic 5.0P trip unit (UL Plug B), LSI functions, 200kA @ 480 volt Modbus, shunt trip- 24-30 Volt AC/DC, pad lockable push button cover, manually operated (M/O), draw-out (D/O), used tested with report.

Square D NW16L1 Masterpact circuit breaker; cat# WA8EER63B3DXBXXXCA, 1600 amp frame, 600 volt AC, 3 pole. With 1600 amp rated Micro logic 5.0P trip unit (UL Plug B), LSI functions, 200kA @ 480 volt Mod bus, shunt trip- 24-30 Volt AC/DC, pad lockable push button cover, manually operated (M/O), draw-out (D/O), used tested with report.

Square D NW16L1 Masterpact circuit breaker; cat# WA8EER63B3DXBXXXCA, 1600 amp frame, 600 volt AC, three pole. With 1600 amp rated micro logic 5.0P trip unit (UL plug B), LSI functions, 200kA @ 480 volt Mod bus, shunt trip- 24-30 Volt AC/DC, pad lockable push button cover, manually operated (M/O), draw-out (D/O), used tested with report.

Square D NW16L1 Masterpact circuit breaker: cat# WA8EER63B3DXBXXXCA 1600 amp frame, 600 volt AC, three pole. With 1600 amp rated Micro logic 5.0P trip with unit UL plug B with LSI functions, 200kA @ 480 volt mod bus, shunt trip- 24-30 Volt AC/DC, pad lockable, push button cover, manually operated (M/O), draw-out (D/O), used tested with report.

Square D NW16L1 Masterpact circuit breaker; cat# WA8EER63B3DXBXXXCA, 1600 amp frame, 600 volt AC, three pole. With 1600 amp rated Micrologic 5.0P trip unit (UL plug B), LSI functions, 200kA @ 480V Modbus, shunt trip- 24-30 Volt AC/DC, pad lockable push button cover, manually operated (M/O), draw-out (D/O), used tested with report.

Square D NW16L1 Masterpact circuit breaker; cat.#WA8EER63B3DXBXXXCA, 1600 amp frame, 600 volt AC, three pole. With 1600 amp rated Micrologic 5.0P trip unit, (UL plug B), LSI functions, 200kA @ 480 volt Modbus, shunt trip- 24-30 volt AC/DC, pad lockable push button cover, manually operated (M/O), draw-out (D/O), used tested with report.

Square D NW16L1 Masterpact circuit breaker: cat# WA8EER64B3DXBXXXCA, 1600 amp frame, 600 volt AC, three pole. With 1600 amp rated (UL plug B) micro logic 6.0P trip unit, LSIG functions, ground fault protection, 200kA @ 480 volt Modbus, shunt trip- 24-30 Volt AC/DC, pad lockable push button cover, manually operated (M/O), draw-out (D/O), used tested with report.

Square D NW16L1 Masterpact circuit breaker; cat.#WA8EER63B3DXBXXXCA, 1600 amp frame, 600 volt AC, three pole. With 1600 amp rated Micro logic 5.0P trip unit (UL plug B) LSI functions, 200kA @ 480 volt Mod bus, shunt trip- 24-30 VAC/DC, pad lockable push button cover, manually operated (M/O), draw-out (D/O), used tested with report.

Square D NW16L1 Masterpact circuit breaker; cat# WA8EER63B3DXBXXXCA, 1600 amp frame, 600 volt AC, three pole. With 1600 amp rated Micrologic 5.0P trip unit (UL plug B), LSI functions, 200kA @ 480 volt modbus, shunt trip- 24-30 Volt AC/DC, pad lockable push button cover, manually operated (M/O), draw-out (D/O), used tested with report. *Chipped Corners*

Square D NW16L1 Masterpact circuit breaker; cat# WA8EER63B3DXBXXXCA, 1600 amp frame, 600 volt AC, three pole. With 1600 amp rated Micro logic 5.0P trip unit, (UL plug B), LSI functions, 200kA @ 480 volt modbus, shunt trip- 24-30 volt AC/DC, pad lockable push button cover, manually operated (M/O), draw-out (D/O), used tested with report. *Chipped Corners*

Square D NW16L1 Masterpact circuit breaker; cat.#WA8EER63B3DXBXXXCA, 1600 amp frame, 600 volt AC, 3 pole. With 1600 amp ratted, micro logic 5.0P trip unit (UL plug B), LSI functions, 200kA @ 480 volt Modbus, shunt trip- 24-30 VAC/DC, pad lockable push button cover, manually operated (M/O), draw-out (D/O), used tested with report.

Square D NW20H1 Masterpact circuit breaker: cat# WA4FFR63A3CFBFXXCX, 2000 amp, 600 volt AC, three pole. With Micro logic 5.0 P trip unit, LSI functions, modbus, spring charging motor- 100-130 VAC, shunt trip- 24-30 VAC/DC, closing coil- 100-130 VAC/DC, electrically operated (E/O), draw-out (D/O), used tested with report.

Square D NW20L1 Masterpact circuit breaker; cat #WA8FFR64A3DXBXXXCA, 2000 amp frame, 600 volt AC, 2000 amp rated. With Micrologic 6.0P trip unit with LSIG functions, ground fault, manually operated (M/O), draw-out (D/O), used tested with report.

Square D NW20L1 Masterpact circuit breaker; cat# WA8FFR64A3DXBXXXCA, 2000 amp frame, 600 volt AC, 3 pole. With 2000 amp rated Micro logic 5.0P trip unit, LSI function, modbus, shunt trip- 24-30 Volt AC/DC, pad lockable, push button cover, manually operated (M/O), draw-out (D/O), used tested with report.

Square D MasterPact NW20N Circuit Breaker; cat# WL1FF33A9SXXXXXXX, 2000 Amp, 600 volt AC, 3 pole. With micrologic 5.0A trip unit, LSI functions, electrically operated (E/O), draw-out (D/O). Used tested with report.

Square D MasterPact NW20N Circuit Breaker; cat# WL1FFR33A9SXXXXXXX, 2000 Amp, 600 volt AC, 3 pole. With micrologic 5.0A trip unit, LSI functions, electrically operated (E/O), draw-out (D/O). Used tested with report.

Square D NW32H1 MasterPact circuit breaker: 3200 amp, 600 volt AC, three pole. With MicroLogic 6.0A unit trip with LSIG functions, ground fault, manually operated (M/O), draw-out (D/O). Used tested with report.

Square D MasterPact NW32H1 Low-Voltage Power Circuit Breaker; cat# WA4JJR64A3CFFFXXCA, 3200 amp, 600 volt AC. With micrologic 6.0P trip unit, manually operated (M/O), roll-out (R/O). Used tested with report. *Missing 1/2 of 1 stab-on clips*

Square D MasterPact NW32H2 Circuit Breaker; Cat # WA5JJR64A3GXXXWXCX, 3200 amp, 600 volt AC, 3 pole, manually operated (M/O), draw-out (D/O). With micrologic 6.0 P trip unit, LSIG functions, ground fault, 3200 amp rating plug. Used tested with report,

Square D MasterPact NW32H3 Circuit Breaker; cat # WA6JJR64D3CFFFXXCX, 3200 amp, 600 volt AC, 3 pole. With micrologic 6.0 P trip unit- LSIG functions- 3200 amp rated, manually operated (M/O), draw-out (D/O). Used tested with report.
