Siemen Switchboard 2000 Amp Main Lug Only 480Y/277 Volt NEMA 1 R&G

Product description:

Siemens Switchboard; 2000 amp, main lug only, 480Y/277 volt, 3 phase, 4 wire. With fusible distribution, Nema 1 indoor. Reconditioned & guaranteed with a one year warranty.

4 Sections: From Right to Left

Distribution 1 Panel

ITE Vacu-Break (3) Switches

• (3) 600 Amp
  • Cat# V7H3606
  • 480 Volt
  • 3 Poles
  • 3 Phase
  • Series A

Distribution 2 Panel

ITE Vacu-Break (6) Switches

• (2) 100 Amp
  • Cat# V7E3633
  • 480 Volt
  • 3 Poles
  • 3 Phase
  • Series A

• (3) 200 Amp
  • Cat# V7F3604
  • 480 Volt

• (1) 600 Amp
  • Cat# VMS366T
  • 480 Volt

Main Lug Only Panel

• 800 Amp Main
  • Cat# QA-0833
  • 480 Volt
  • Serial # A53347S

Distribution 3 Panel

ITE Vacu-Break (6) Switches

• (2) 100 Amp
  • Cat # V7E3633
  • 480 Volt
  • 3 Poles
  • 3 Phase
  • Series A

• (3) 200 Amp
  • Cat # V7F3604
  • 480 Volt

• (1) 600 Amp
  • Cat# VMS366T
  • 480 Volt

Dimensions: 4 Sections

• Distribution 1 Panel

  • 38" Width
  • 38" Depth
  • 90" Height

• Distribution 2 Panel
  • 38" Width
  • 38" Depth
  • 90" Height

• MLO Panel
  • 38" Width
  • 38" Depth
  • 90" Height

• Distribution 3 Panel
  • 38" Width
  • 38" Depth
  • 90" Height

Reconditioned & guaranteed with a one year warranty
