Siemens 3000 Amp Fusible Main Switchboard 480Y/277 Volt 3Ph 4W GFI W/ Distribution NEMA 1 R&G

Product description:

Siemens fusible switchboard; 3000 amp Pringle switch fusible main, cat# FP3034-B, 480 volt, 3 phase, 4 wire, ground fault, NEMA 1 indoor. With 2000 amp fusible distribution Pringle switch, & 6 total distribution sections. Reconditioned & guaranteed with a one-year warranty.

8 Sections: From Left to Right

Pull Section

• AMMETER
• VOLTMETER

Main Fusible Section

• Pringe Main Fusible Switch
  • 3000 Amp
  • 480 Volt
  • 3 Phase
  • 4 Wire
  • Cat# FP3034-B
  • Ground Fault Protector
    • GFP Monitor & Test

Fusible Distribution Section 1

• Pringle Distribution Switch
  • 2000 Amp
  • 480 Volt
  • Cat# QA-2033-B

Distribution Section 2

• ITE/ Gould Vacu-Break Fusible Switch
  • VF-357TL
  • 800 Amp
  • 480 Volt

Distribution Section 3

• (1) ITE/ Gould Vacu-Break Fusible Switch
  • 600 Amp
  • 480 Volt
  • Cat# V7H3606

• (1) ITE/ Gould Vacu-Break Fusible Switch
  • 400 Amp
  • 480 Volt
  • Cat# V7H3605

• (3) ITE/ Gould Vacu-Break Fusible Switches
  • 200 Amp
  • 480 Volt
  • Cat# V7F3604

Distribution Section 4

• (1) ITE/ Gould Fusible Switches
  • 600 Amp
  • 480 Volt
  • Cat# V7H3606

• (1) 800 Amp Breaker
  • Top Fed
  • Neutral Ground

• (4) ITE/ Gould Fusible Switches
  • 100 Amp
  • 480 Volt
  • Cat# V7E3633

Distribution Section 5

• Bulldog Fusible Switch

  • Cat# V7-3606
  • 600 Amp
  • 480 Volt
  • 3 Pole

• Siemens Sensitrip III Electronic Circuit Breaker
  • 1200 Amp
  • Cat# SND69120ANT
  • 480 Volt
  • 3 Pole
  • Type SND6
  • LSI functions

• (2) ITE/ Gould Vacu-Break Fusible Switches
  • Cat# V7F3604
  • 200 Amp
  • 480 Volt

Distribution Section 6

• (2) ITE/ Siemens Vacu-Break Switch
  • 100 Amps
  • Cat# V7E3633
  • 480 Volt
  • Series A

Dimensions:

Pull Section

• 38" Length
• 38" Depth
• 90" Height

Main Section

• 46" Length
• 38" Depth
• 90" Height

Distribution Sections 1-6

• 38" Length
• 38" Depth
• 90" Height

(M-520       LOC:  Pillar 105)
