Siemens

Siemens Low Voltage Dry Type Transformer: Cat # 3F1Y500, 500 KVA, primary voltage: 480 volt, secondary voltage: 240Y/120 volt, 3 phase, NEMA 1 indoor. Reconditioned & guaranteed with a one-year warranty.

Siemens 8100 Class E2 Motor Controller: Group Arrangement# 25-319-343-501, Set Voltage: 4160 Volt, 3 Phase, Set Horsepower: 300HP, Set Amperage: 39.6 Full Load Amps. Auto Transformer with Taps Vacuum Contactors (A&B Contactors)- 3TL6116-OAK2, 360 Amps, 5KV, 120 Volt AC Control Voltage. Non-Fused (C Contactor)- 88H353304A3A, 360 Amps, 5KV, 115 Volt AC Control Voltage. Fused Control Transformer: 2.0KVA, 4000-115 Volt, w/ 2E Fuses. Siemens 3UA59 Overload- 2.64 Dial Setting/Trip 1200 Amps. Reconditioned & guaranteed with a one year warranty.

Siemens 8100 Class E2 Motor Controller: #25-321-850-501, Set Voltage: 4160 Volt, 3 Phase, Set Horsepower: 1250HP. (Auto-Transformer Sold Set Amperage: 148 Full Load Amps, Auto Transformer with Taps, Vacuum Contactors (A&B - Contactors)- 3TL8107-1BA00, 360 Amps, 7.5KV, 120 Volt AC Control Voltage. Non-Fused (C - Contactor)- 3TL8107-1BA00, 360 Amps, 5KV, 120 Volt AC Control Voltage. Fused Control Transformer: 2.0KVA, 4000-115 Volt, w/ 2E Fuses. 1000 Amps. Reconditioned & guaranteed with a one-year warranty.

Siemens Cubicle Bus WLS2F312 Circuit Breaker; Cat # S2F312QVXXXXXBN, 1200 amp, 600 volt AC, 3 pole, manually operated (M/O), fixed-mount (F/M). With ETU776 trip unit, 1200 amp rating plug. Used tested with report.

Siemens F2 Series Panelboard; main lug only, 1000 amp, 208Y/120 volt, Nema 1. With (3)-V7H3205 Switches (400A) & (1)-V2E2204LM Switch (200A, 2P). Reconditioned & guaranteed with a one-year warranty.

Siemens F2 Series Panelboard; main lug only, 800 amp, 480Y/277 volt, Nema 1. With (3) V7HF3604 200 amp switches. Reconditioned & guaranteed with a one-year warranty.

Siemens FC-I style Switchboard; 1600 amp, 480 volt, three phase, four wire. QA1633 main fusible panel. Reconditioned & guaranteed with a one year warranty. Contact EMSCO today to discuss this panel.

Siemens ITE FCI Switchboard; main lug only, 1600 amp max, 480Y/277 volt, 3 phase, 4 wire, NEMA 1 indoor rated. With V7 distribution switches. Reconditioned & guaranteed with a one-year warranty.

Siemens Model 95 MCC; 225 amp breaker main, 480Y/277 volt. With (2) Size 1 FVNR Starter buckets with breaker disconnects. Reconditioned & guaranteed with a one-year warranty.

Siemens Model 95 MCC; 600 amp, main lug only, 480Y/277 volt. With (1) Size 5 FVNR starter bucket with fusible disconnects & (1) 200 Amp fusible feeder bucket. Reconditioned & guaranteed with a one-year warranty.

Siemens Model 95 MCC; 600 amp, main lug only, 480Y/277 volt. With (3) size 3 FVNR starter buckets with breaker disconnects, (1) size 1 FVNR starter buckets with breaker disconnects, & (2) breaker feeder buckets. Reconditioned & guaranteed with a one-year warranty.

Siemens Model 95 MCC; 600 amp, main lug only, 480Y/277 volt. With (1) CED 100 amp breaker feeder bucket & (4) Size 1 FVNR starter buckets with breaker disconnects. Reconditioned & guaranteed with a one-year warranty.

Siemens Model 95 MCC; 600 amp, main lug only, 480Y/277 volt. With (8) Size 1 FVNR starter bucket with fusible disconnects, (3) Size 2 FVNR starter bucket with fusible disconnects, & (6) Size 3 FVNR starter bucket with fusible disconnects. Reconditioned & guaranteed with a one-year warranty.

Siemens Model 95 MCC; 800 amp, main lug only, 480Y/277 volt. With (1) Size 5 FVNR starter bucket with breaker disconnects, (9) Size 1 FVNR starter buckets with fusible disconnects, (1) 100 amp fusible feeder bucket, & (1) 60 amp fusible feeder bucket. Reconditioned & guaranteed with a one year warranty.

Siemens MSB Switchboard; 3000 amp, QA-3033-CBC fusible main, 208Y/120 volt, NEMA 1 indoor. Reconditioned & guaranteed with a one year warranty

Siemens RLX-800 low voltage AC power circuit breaker; 600 volt, 800 amp. Manually operated, draw-out (No Trip Unit). Used Electrically OK.

Siemens S5 Series Panelboard; 800 amp main breaker, 208Y/120 volt, Nema 1. With (1)- BL330H Breaker (30 Amp), (8)- BL3100H Breakers (100 Amp), & (2)- QJH23B225 Breakers (225 Amp). Reconditioned & guaranteed with a one-year warranty.

Siemens SB Switchboard; 2000 amp fusible main, 208Y/120 volt, 3 phase, 4 wire, NEMA 1 indoor rated. With 1 section of fusible distribution switches. Reconditioned & guaranteed with a one-year warranty.

Siemens SB3 Switchboard; 1200 amp, CBC-1233-S fusible main, 480Y/277 volt with ground fault, Nema 1 indoor. Reconditioned & guaranteed with a one year warranty.

Siemens SB3 Switchboard; 2500 amp, cat# SBS4025, 480Y/277 volt, 3 phase, 4 wire, LSIG functions, ground fault, NEMA 1 indoor rated. Reconditioned & guaranteed with a one-year warranty.
